Schema

Utilize nossa biblioteca criada em C# para gerar um arquivo XML que represente uma Nota Fiscal Eletrônica. RDI.NFe2.Schema.dll já está revisada com campos acrescentados pela Reforma Tributária.

Como funciona?

1

Baixe a biblioteca

Escolha a biblioteca de acordo com a versão de .NET que seu projeto utiliza.

2

Adicione ao projeto

Como você faria com qualquer outra biblioteca.

3

Gere o XML

Utilize o código abaixo para gerar sua NFe.

Exemplo de uso da Biblioteca

Observe a seguir um exemplo de código fonte em C# já utilizando campos da Reforma Tributária como IBS e CBS. O método a ser chamado é ObterXMLNFe, enviando um objeto que represente uma Nota de Produto. A classe NotaProduto representa uma estrutura montada pelo seu ERP e que possua emitente, destinatário, itens da nota, endereço de entrega, enfim, um Nota Fiscal de Produtos. Os enums TipoPessoa, TipoEntradaSaida, TipoFinalidade, TipoModalidadeFrete, TipoMeioPagamento, TipoFormaPgto, CST e CSOSNICMS são sugeridos ao final do código. Modifique o código de acordo com a realidade do seu software.


using RDI.NFe2.SchemaXML.NFe_v400;
using RDI.NFe2.SchemaXML;
...

public static string ObterXMLNFe(NotaProduto notaProduto)
{
    var nfe = ObterNFe(notaProduto);
    var stXML = XMLUtils.GetXML(nfe, VersaoXML.NFe_v400);

    return stXML;
}


public static string DvBase11(string Numero)
{
    try
    {
        int num = 2;
        int num2 = 0;
        for (int num3 = Numero.Length - 1; num3 >= 0; num3--)
        {
            num2 += int.Parse(Numero[num3].ToString()) * num;
            num++;
            if (num > 9)
            {
                num = 2;
            }
        }

        num2 %= 11;
        if (num2 > 1)
        {
            return (11 - num2).ToString();
        }

        return "0";
    }
    catch (Exception ex)
    {
        throw new Exception("Erro na geração da chave de acesso." + ex.Message);
    }
}

public static TUfEmi StringToUFEmi(string siglaEstado)
{
    var ufs = Enum.GetValues(typeof(TUfEmi));
    foreach(TUfEmi uf in ufs)
    {
        if (uf.ToString() == siglaEstado.ToUpper())
            return uf;
    }

    throw new Exception("Sigla de Estado inválida: " + siglaEstado);
}

public static TUf StringToUF(string siglaEstado)
{
    var ufs = Enum.GetValues(typeof(TUf));
    foreach (TUf uf in ufs)
    {
        if (uf.ToString() == siglaEstado.ToUpper())
            return uf;
    }

    throw new Exception("Sigla de Estado inválida: " + siglaEstado);
}

public static string DecimalToString(Decimal valor)
{
    return valor.ToString("N2").Replace(".", "").Replace(',', '.');
}

// Sugestão de enums para o seu ERP:
/*  public enum TipoPessoa
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "Física", value = "F")]
        Fisica,
        [EnumeratedItemInfo(description = "Jurídica", value = "J")]
        Juridica
    }

    public enum TipoFinalidade
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "Normal", value = "1")]
        Normal,
        [EnumeratedItemInfo(description = "NFe Complementar", value = "2")]
        NFeComplementar,
        [EnumeratedItemInfo(description = "NFe Ajuste", value = "3")]
        NFeAjuste,
        [EnumeratedItemInfo(description = "Devolução", value = "4")]
        Devolucao,
    }


    public enum TipoFormaPgto
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "À Vista", value = "0")]
        AVista,
        [EnumeratedItemInfo(description = "À Prazo", value = "1")]
        APrazo,
        [EnumeratedItemInfo(description = "Outros", value = "2")]
        Outros,
    }

    public enum TipoMeioPagamento
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "Dinheiro", value = "D")]
        Dinheiro,
        [EnumeratedItemInfo(description = "Cheque", value = "C")]
        Cheque,
        [EnumeratedItemInfo(description = "Cartão de Crédito", value = "3")]
        CartaoCredito,
        [EnumeratedItemInfo(description = "Cartão de Débito", value = "4")]
        CartaoDebito,
        [EnumeratedItemInfo(description = "Crédito Loja", value = "L")]
        CreditoLoja,
        [EnumeratedItemInfo(description = "Vale Alimentação", value = "A")]
        ValeAlimentacao,
        [EnumeratedItemInfo(description = "Vale Refeição", value = "R")]
        ValeRefeicao,
        [EnumeratedItemInfo(description = "Vale Presente", value = "P")]
        ValePresente,
        [EnumeratedItemInfo(description = "Vale Combustível", value = "X")]
        ValeCombustivel,
        [EnumeratedItemInfo(description = "Duplicata Mercantil", value = "M")]
        DuplicataMercantil,
        [EnumeratedItemInfo(description = "Boleto Bancário", value = "B")]
        BoletoBancario,
        [EnumeratedItemInfo(description = "Depósito Bancário", value = "5")]
        DepositoBancario,
        [EnumeratedItemInfo(description = "Pagamento Instantâneo (PIX)", value = "6")]
        PIX,
        [EnumeratedItemInfo(description = "Transferência bancária, Carteira Digital", value = "7")]
        TransferenciaBancaria,
        [EnumeratedItemInfo(description = "Programa de fidelidade, Cashback, Crédito Virtual", value = "8")]
        Cashback,
        [EnumeratedItemInfo(description = "Sem pagamento", value = "S")]
        SemPagamento,
        [EnumeratedItemInfo(description = "Outros", value = "O")]
        Outros
    }

    public enum TipoEntradaSaida
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "Entrada", value = "E")]
        Entrada,
        [EnumeratedItemInfo(description = "Saída", value = "S")]
        Saida,
        [EnumeratedItemInfo(description = "Estorno-Entrada", value = "N")]
        EstornoEntrada,
        [EnumeratedItemInfo(description = "Estorno-Saída", value = "A")]
        EstornoSaida
    }

    public enum CST
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "000 - Tributação integral", value = "A")]
        Item000,
        [EnumeratedItemInfo(description = "010 - Tributação com alíquotas uniformes", value = "B")]
        Item010,
        [EnumeratedItemInfo(description = "011 - Tributação com alíquotas uniformes reduzidas", value = "C")]
        Item011,
        [EnumeratedItemInfo(description = "200 - Alíquota reduzida", value = "D")]
        Item200,
        [EnumeratedItemInfo(description = "220 - Alíquota fixa", value = "E")]
        Item220,
        [EnumeratedItemInfo(description = "221 - Alíquota fixa proporcional", value = "F")]
        Item221,
        [EnumeratedItemInfo(description = "222 - Redução de Base de Cálculo", value = "G")]
        Item222,
        [EnumeratedItemInfo(description = "400 - Isenção", value = "H")]
        Item400,
        [EnumeratedItemInfo(description = "410 - Imunidade e não incidência", value = "I")]
        Item410,
        [EnumeratedItemInfo(description = "510 - Diferimento", value = "J")]
        Item510,
        [EnumeratedItemInfo(description = "515 - Diferimento com redução de alíquota", value = "K")]
        Item515,
        [EnumeratedItemInfo(description = "550 - Suspensão", value = "L")]
        Item550,
        [EnumeratedItemInfo(description = "620 - Tributação Monofásica", value = "M")]
        Item620,
        [EnumeratedItemInfo(description = "800 - Transferência de crédito", value = "N")]
        Item800,
        [EnumeratedItemInfo(description = "810 - Ajuste de IBS na ZFM", value = "O")]
        Item810,
        [EnumeratedItemInfo(description = "811 - Ajustes", value = "P")]
        Item811,
        [EnumeratedItemInfo(description = "820 - Tributação em declaração de regime específico", value = "Q")]
        Item820,
        [EnumeratedItemInfo(description = "830 - Exclusão da Base de Cálculo", value = "R")]
        Item830,
    }

    public enum CSOSNICMS
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "SIMPLES: 101 - Tributada pelo Simples Nacional com permissão de crédito", value = "A")]
        ItemSIMPLES101,
        [EnumeratedItemInfo(description = "SIMPLES: 102 - Tributada pelo Simples Nacional sem permissão de crédito", value = "B")]
        ItemSIMPLES102,
        [EnumeratedItemInfo(description = "SIMPLES: 103 - Isenção do ICMS no Simples Nacional para faixa de receita bruta", value = "C")]
        ItemSIMPLES103,
        [EnumeratedItemInfo(description = "SIMPLES: 300 - Imune", value = "D")]
        ItemSIMPLES300,
        [EnumeratedItemInfo(description = "SIMPLES: 400 - Não tributada pelo Simples Nacional", value = "E")]
        ItemSIMPLES400,
        [EnumeratedItemInfo(description = "SIMPLES: 201 -Tributada pelo Simples Nacional com permissão de crédito e com cobrança do ICMS por Substituição Tributária", value = "F")]
        ItemSIMPLES201,
        [EnumeratedItemInfo(description = "SIMPLES: 202 - Tributada pelo Simples Nacional sem permissão de crédito e com cobrança do ICMS por Substituição Tributária", value = "G")]
        ItemSIMPLES202,
        [EnumeratedItemInfo(description = "SIMPLES: 203 - Isenção do ICMS nos Simples Nacional para faixa de receita bruta e com cobrança do ICMS por Substituição Tributária", value = "H")]
        ItemSIMPLES203,
        [EnumeratedItemInfo(description = "SIMPLES: 500 - ICMS cobrado anteriormente por substituição tributária (substituído) ou por antecipação", value = "I")]
        ItemSIMPLES500,
        [EnumeratedItemInfo(description = "SIMPLES: 900 - Outros", value = "J")]
        ItemSIMPLES900,
    }

    public enum TipoModalidadeFrete
    {
        [EnumeratedItemInfo(description = "", value = "")]
        Vazio,
        [EnumeratedItemInfo(description = "Por conta do Emitente", value = "0")]
        Emitente,
        [EnumeratedItemInfo(description = "Por conta do Destinatário/Remetente", value = "1")]
        Remetente,
        [EnumeratedItemInfo(description = "Por conta de Terceiros", value = "2")]
        Terceiros,
        [EnumeratedItemInfo(description = "Sem Frete", value = "9")]
        SemFrete,
    }

    */


//Considere a seguir que NotaProduto seja um DTO representando uma Nota Fiscal de Produto
public static TNFe ObterNFe(NotaProduto np)
{
    //Dados da nota
    var oNotaXML = new TNFe();

    oNotaXML.infNFe = new TNFeInfNFe();

    oNotaXML.infNFe.ide = new TNFeInfNFeIde();
    oNotaXML.infNFe.ide.cUF = (TCodUfIBGE)np.uf.codigoIBGE;

    if (!String.IsNullOrWhiteSpace(np.naturezaOperacao))
        if (np.naturezaOperacao.Length > 60)
            throw new Exception("Natureza da Operação deve possuir no máximo 60 caracteres.");

    oNotaXML.infNFe.ide.natOp = np.naturezaOperacao;
    oNotaXML.infNFe.ide.indPres = TNFeInfNFeIdeIndPres_v400.Item1;

    // nota referenciada, usada em processos de devolução
    if (!String.IsNullOrEmpty(np.chaveNotaReferenciada))
    {
        if (oNotaXML.infNFe.ide.NFref == null)
        {
            oNotaXML.infNFe.ide.NFref = new TNFeInfNFeIdeNFref[1];
            oNotaXML.infNFe.ide.NFref[0] = new TNFeInfNFeIdeNFref();
            ((TNFeInfNFeIdeNFref)oNotaXML.infNFe.ide.NFref[0]).Item = np.chaveNotaReferenciada;
            ((TNFeInfNFeIdeNFref)oNotaXML.infNFe.ide.NFref[0]).ItemElementName = ITCTypeRefNF.refNFe;
        }
    }

    oNotaXML.infNFe.pag = new TNFeInfNFePag();
    oNotaXML.infNFe.pag.detPag = new TNFeInfNFePagDetPag[1];
    oNotaXML.infNFe.pag.detPag[0] = new TNFeInfNFePagDetPag();
    oNotaXML.infNFe.pag.detPag[0].indPagSpecified = true;

    switch (np.tipoFormaPagamento)
    {
        case TipoFormaPgto.APrazo:
        {
            oNotaXML.infNFe.pag.detPag[0].indPagSpecified = true;
            oNotaXML.infNFe.pag.detPag[0].indPag = TIndPag_v400.APrazo;
            break;
        }
        case TipoFormaPgto.AVista:
        {
            oNotaXML.infNFe.pag.detPag[0].indPagSpecified = true;
            oNotaXML.infNFe.pag.detPag[0].indPag = TIndPag_v400.AVista;
            break;
        }
        case TipoFormaPgto.Outros:
        {
            oNotaXML.infNFe.pag.detPag[0].indPagSpecified = false;
            break;
        }
        default:
            throw new Exception("Tipo de forma de pagamento inválido para NFe v4.0. Favor conferir.");
    }

    switch (np.tipoMeioPagamento)
    {
        case TipoMeioPagamento.Dinheiro:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item01;
            break;
        }
        case TipoMeioPagamento.Cheque:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item02;
            break;
        }
        case TipoMeioPagamento.CartaoCredito:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item03;
            break;
        }
        case TipoMeioPagamento.CartaoDebito:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item04;
            break;
        }
        case TipoMeioPagamento.CreditoLoja:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item05;
            break;
        }
        case TipoMeioPagamento.ValeAlimentacao:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item10;
            break;
        }
        case TipoMeioPagamento.ValeRefeicao:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item11;
            break;
        }
        case TipoMeioPagamento.ValePresente:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item12;
            break;
        }
        case TipoMeioPagamento.ValeCombustivel:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item13;
            break;
        }
        case TipoMeioPagamento.DuplicataMercantil:
        {
            throw new Exception("Meio de pagamento 'Duplicata Mercantil' é inválido para NFe v4.0.");
            break;
        }

        case TipoMeioPagamento.BoletoBancario:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item15;
            break;
        }

        case TipoMeioPagamento.DepositoBancario:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item16;
            break;
        }

        case TipoMeioPagamento.PIX:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item17;
            break;
        }

        case TipoMeioPagamento.TransferenciaBancaria:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item18;
            break;
        }

        case TipoMeioPagamento.Cashback:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item19;
            break;
        }


        case TipoMeioPagamento.SemPagamento:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item90;
            break;
        }

        case TipoMeioPagamento.Outros:
        {
            oNotaXML.infNFe.pag.detPag[0].tPag = TNFeInfNFePagDetPagTPag.Item99;
            oNotaXML.infNFe.pag.detPag[0].xPag = "Outros";
            break;
        }
    }

    oNotaXML.infNFe.ide.dhEmi = np.dataEmissao.ToString("yyyy-MM-ddTHH:mm:sszzzz");

    if (np.paisDestinatario.codigoBACEN == 1058) // Brasil
    {
        if (np.uf.UFeSigla == np.estadoDestinatario.UFeSigla)
            oNotaXML.infNFe.ide.idDest = TNFeInfNFeIdeIdDest.OperacaoInterna;
        else
            oNotaXML.infNFe.ide.idDest = TNFeInfNFeIdeIdDest.OperacaoInterestadual;
    }
    else
        oNotaXML.infNFe.ide.idDest = TNFeInfNFeIdeIdDest.OperacaoExterior;

    oNotaXML.infNFe.ide.cMunFG = np.cidadeEmit.codigoIBGE.ToString();
    oNotaXML.infNFe.ide.tpImp = TNFeInfNFeIdeTpImp.Item1;
    oNotaXML.infNFe.ide.tpAmb = np.producao ? TAmb.Producao : TAmb.Homologacao;

    switch (np.finalidade)
    {
        case TipoFinalidade.Normal:
        {
            oNotaXML.infNFe.ide.finNFe = TFinNFe_v310_v400.Normal;
            break;
        }
        case TipoFinalidade.Devolucao:
        {
            oNotaXML.infNFe.ide.finNFe = TFinNFe_v310_v400.Devolucao;
            break;
        }
        case TipoFinalidade.NFeAjuste:
        {
            oNotaXML.infNFe.ide.finNFe = TFinNFe_v310_v400.NFeAjuste;
            break;
        }
        case TipoFinalidade.NFeComplementar:
        {
            oNotaXML.infNFe.ide.finNFe = TFinNFe_v310_v400.NFeComplementar;
            break;
        }
        default:
        {
            throw new Exception("Finalidade não compatível com NFe 4.0. Favor conferir.");
        }
    }

    oNotaXML.infNFe.ide.indPres = 0;
    oNotaXML.infNFe.ide.verProc = "SISTEMA.v1.1.1";
    if (np.tipo == TipoEntradaSaida.Entrada)
        oNotaXML.infNFe.ide.tpNF = TNFeInfNFeIdeTpNF.Entrada;
    else
        oNotaXML.infNFe.ide.tpNF = TNFeInfNFeIdeTpNF.Saida;

    oNotaXML.infNFe.emit = new TNFeInfNFeEmit();
    oNotaXML.infNFe.emit.ItemElementName = ITCTypeCNPJCPF.CNPJ;
    oNotaXML.infNFe.emit.Item = np.documentoEmitente;
    oNotaXML.infNFe.emit.xNome = np.nomeEmitente;

    oNotaXML.infNFe.emit.IE = np.inscricaoEstadualEmitente
                                .Replace(".", "").Replace(" ", "").Replace("-", "");

    oNotaXML.infNFe.emit.CRT = TNFeInfNFeEmitCRT.Item1;

    oNotaXML.infNFe.emit.enderEmit = new TEnderEmi();
    oNotaXML.infNFe.emit.enderEmit.xLgr = np.logradouroEndEmitente;
    oNotaXML.infNFe.emit.enderEmit.nro = np.numeroEndEmitente;
    oNotaXML.infNFe.emit.enderEmit.xCpl = np.complementoEndEmitente;
    oNotaXML.infNFe.emit.enderEmit.xBairro = np.bairroEndEmitente;
    oNotaXML.infNFe.emit.enderEmit.cMun = np.cidadeEmit.codigoIBGE.ToString();
    oNotaXML.infNFe.emit.enderEmit.xMun = np.cidadeEmit.nome;
    oNotaXML.infNFe.emit.enderEmit.UF = StringToUFEmi(np.uf.UFeSigla);
    oNotaXML.infNFe.emit.enderEmit.CEP = np.cepEndEmitente.Replace("-", "").Replace(" ", "");
    oNotaXML.infNFe.emit.enderEmit.cPais = TEnderEmiCPais.Item1058; // Brasil
    oNotaXML.infNFe.emit.enderEmit.xPais = TEnderEmiXPais.BRASIL;
    oNotaXML.infNFe.emit.enderEmit.fone = np.telefoneEmitente
                                            .Replace("-", "").Replace(" ", "")
                                            .Replace("(", "").Replace(")", "");

    oNotaXML.infNFe.dest = new TNFeInfNFeDest();

    TipoPessoa tipoDocumentoDestinatario = TipoPessoa.Vazio;

    if (np.pessoa != null)
        tipoDocumentoDestinatario = np.pessoa.tipoPessoa;
    else
        tipoDocumentoDestinatario = np.tipoDocumentoDestinatario;

    if (tipoDocumentoDestinatario == TipoPessoa.Vazio)
        throw new Exception("Tipo de Documento do Destinatário não foi encontrado.");

    var exportacao = false;

    if (tipoDocumentoDestinatario == TipoPessoa.Fisica)
        oNotaXML.infNFe.dest.ItemElementName = ITCTypeCNPJCPFIdEstrangeiro.CPF;
    else if (tipoDocumentoDestinatario == TipoPessoa.Juridica)
    {
        if (np.oPaisDestinatario.codigoBACEN == 1058) // Brasil
            oNotaXML.infNFe.dest.ItemElementName = ITCTypeCNPJCPFIdEstrangeiro.CNPJ;
        else // Exterior
        {
            exportacao = true;
            oNotaXML.infNFe.dest.ItemElementName = ITCTypeCNPJCPFIdEstrangeiro.idEstrangeiro;
        }
    }

    oNotaXML.infNFe.dest.Item = np.documentoDestinatario;

    string nomeDest = np.nomeDestinatario;

    if (nomeDest.Length > 60)
        nomeDest = nomeDest.Substring(0, 60);

    if (np.producao)
        oNotaXML.infNFe.dest.xNome = nomeDest.Trim();
    else
        oNotaXML.infNFe.dest.xNome = "NF-E EMITIDA EM AMBIENTE DE HOMOLOGACAO - SEM VALOR FISCAL";


    //9 = Não Contribuinte, que pode ou não possuir Inscrição Estadual no Cadastro de Contribuintes
    if (string.IsNullOrEmpty(np.inscricaoEstadualDestinatario))
    {
        oNotaXML.infNFe.dest.indIEDest = TNFeInfNFeDestIndIEDest.Item9;
        oNotaXML.infNFe.ide.indFinal = TNFeInfNFeIdeIndFinal.ConsumidorFinal;
    }
    //2 = Contribuinte isento de Inscrição no cadastro de Contribuintes do ICMS;
    else if (np.inscricaoEstadualDestinatario.ToUpper() == "ISENTO")
    {
        oNotaXML.infNFe.ide.indFinal = TNFeInfNFeIdeIndFinal.ConsumidorFinal;
        oNotaXML.infNFe.dest.indIEDest = TNFeInfNFeDestIndIEDest.Item2;
    }
    //1 = Contribuinte ICMS(informar a IE do destinatário);
    else
    {
        oNotaXML.infNFe.ide.indFinal = TNFeInfNFeIdeIndFinal.Normal;
        oNotaXML.infNFe.dest.IE = np.inscricaoEstadualDestinatario
                                    .Replace(".", "").Replace(" ", "").Replace("-", "");
        oNotaXML.infNFe.dest.indIEDest = TNFeInfNFeDestIndIEDest.Item1;
    }

    if (!string.IsNullOrEmpty(np.emailDestinatario))
    {
        var emailDestinatario = np.emailDestinatario.Trim();

        if (emailDestinatario.Length > 60)
            throw new Exception("E-mail do Destinatário supera 60 caracteres.");

        oNotaXML.infNFe.dest.email = emailDestinatario;
    }

    oNotaXML.infNFe.dest.enderDest = new TEndereco();
    oNotaXML.infNFe.dest.enderDest.xLgr = np.logradouroEndDestinatario;
    oNotaXML.infNFe.dest.enderDest.nro = np.numeroEndDestinatario;
    oNotaXML.infNFe.dest.enderDest.xBairro = np.bairroEndDestinatario;
    oNotaXML.infNFe.dest.enderDest.xCpl = np.complementoEndDestinatario;

    if (np.cidadeDestinatario == null)
        throw new Exception("Cidade do Destinatário não informada.");

    oNotaXML.infNFe.dest.enderDest.cMun = np.cidadeDestinatario.codigoIBGE.ToString();
    oNotaXML.infNFe.dest.enderDest.xMun = np.cidadeDestinatario.nome;

    if (np.estadoDestinatario == null)
        throw new Exception("Estado do Destinatário não informado.");


    oNotaXML.infNFe.dest.enderDest.UF = StringToUF(np.estadoDestinatario.UFeSigla);
    oNotaXML.infNFe.dest.enderDest.CEP = np.cepEndDestinatario
                                           .Replace("-", "").Replace(" ", "").Replace(".", "");

    if (np.paisDestinatario == null)
        throw new Exception("País do Destinatário não informado.");

    oNotaXML.infNFe.dest.enderDest.cPais = np.paisDestinatario.codigoBACEN.ToString();
    oNotaXML.infNFe.dest.enderDest.xPais = np.paisDestinatario.nome;

    if (!string.IsNullOrEmpty(np.telefoneDestinatario))
        oNotaXML.infNFe.dest.enderDest.fone = np.telefoneDestinatario
                                                .Replace("-", "").Replace(" ", "")
                                                .Replace("(", "").Replace(")", "");


    var i = 0;
    oNotaXML.infNFe.det = new TNFeInfNFeDet[np.itens.Count];

    decimal totalIPIDevolucao = np.itens.Sum(x => x.valorIPIDevolucao);
    string strVIPIDEV = DecimalToString(totalIPIDevolucao);
    bool devolverIPI = totalIPIDevolucao > 0;

    foreach (var item in np.itens)
    {
        oNotaXML.infNFe.det[i] = new TNFeInfNFeDet();
        oNotaXML.infNFe.det[i].nItem = (i + 1).ToString();

        oNotaXML.infNFe.det[i].prod = new TNFeInfNFeDetProd();
        oNotaXML.infNFe.det[i].prod.cProd = item.produto.codigo.ToString();
        oNotaXML.infNFe.det[i].prod.cEAN = "SEM GTIN";

        if (item.descricaoProduto.Length > 120)
            throw new Exception("Descrição do Produto supera 120 caracteres.");


        oNotaXML.infNFe.det[i].prod.xProd = item.descricaoProduto;
        oNotaXML.infNFe.det[i].prod.NCM = item.ncm;
        oNotaXML.infNFe.det[i].prod.CFOP = item.CFOP.ToString();
        oNotaXML.infNFe.det[i].prod.uCom = item.unidade;
        oNotaXML.infNFe.det[i].prod.cEANTrib = "SEM GTIN";
        oNotaXML.infNFe.det[i].prod.uTrib = item.unidade;
        oNotaXML.infNFe.det[i].prod.qCom = item.quantidade.ToString("N4")
                                                    .Replace(".", "").Replace(',', '.');
        oNotaXML.infNFe.det[i].prod.qTrib = item.quantidade.ToString("N4")
                                                    .Replace(".", "").Replace(',', '.');
        oNotaXML.infNFe.det[i].prod.vUnCom = item.valorUnitario.ToString("N10")
                                                    .Replace(".", "").Replace(',', '.');
        oNotaXML.infNFe.det[i].prod.vUnTrib = item.valorUnitario.ToString("N10")
                                                    .Replace(".", "").Replace(',', '.');
        oNotaXML.infNFe.det[i].prod.vProd = DecimalToString(item.quantidade * item.valorUnitario);

        if (item.valorDesconto > 0)
            oNotaXML.infNFe.det[i].prod.vDesc = DecimalToString(item.valorDesconto);

        if (item.valorFrete > 0)
            oNotaXML.infNFe.det[i].prod.vFrete = DecimalToString(item.valorFrete);

        oNotaXML.infNFe.det[i].prod.indTot = TNFeInfNFeDetProdIndTot.Item1;

        if (!String.IsNullOrEmpty(item.numeroPedidoCompra))
        {
                if (item.numeroPedidoCompra.Length > 15)
                    throw new Exception("Número Pedido Compra do Produto supera 15 caracteres.");

                oNotaXML.infNFe.det[i].prod.xPed = item.numeroPedidoCompra;
        }

        if (!String.IsNullOrEmpty(item.itemPedidoCompra))
        {
                if (item.itemPedidoCompra.Length > 6)
                    throw new Exception("Item Pedido Compra do Produto supera 6 caracteres.");

                oNotaXML.infNFe.det[i].prod.nItemPed = item.itemPedidoCompra;
        }

        oNotaXML.infNFe.det[i].imposto = new TNFeInfNFeDetImposto();

        string vBCPIS = DecimalToString(item.bcPIS);
        string pPIS = DecimalToString(item.percPIS);
        string vPIS = DecimalToString(item.valorPIS);

        string vBCCOFINS = DecimalToString(item.bcCOFINS);
        string pCOFINS = DecimalToString(item.percCOFINS);
        string vCOFINS = DecimalToString(item.valorCOFINS);

        string vBCICMS = DecimalToString(item.bcICMS);
        string pICMS = DecimalToString(item.percICMS);
        string vICMS = DecimalToString(item.valorICMS);

        string vBCIPI = DecimalToString(item.bcIPI);
        string pIPI = DecimalToString(item.percIPI);
        string vIPI = DecimalToString(item.valorIPI);

        string vBCIBS = DecimalToString(item.bcIBS);
        string vBCCBS = DecimalToString(item.bcCBS);
        string vBCIBSCBS = DecimalToString(item.bcIBS);
        string vIBSMunicipio = DecimalToString(item.valorIBSMunicipio);

        string vIBSUF = DecimalToString(item.valorIBSUF);
        string vIBS = DecimalToString(item.valorIBS);
        string vCBS = DecimalToString(item.valorCBS);

        string pIBS = item.percIBS.ToString("N4").Replace(".", "").Replace(',', '.');
        string pCBS = item.percCBS.ToString("N4").Replace(".", "").Replace(',', '.');
        string pIBSUF = (item.percIBSUF / 100 * item.percIBS)
                                .ToString("N4").Replace(".", "").Replace(',', '.');
        string pIBSMunicipio = (item.percIBSMunicipio / 100 * item.percIBS)
                                .ToString("N4").Replace(".", "").Replace(',', '.');

        if (devolverIPI)
        {
            string VIPIDEVOLVIDO = DecimalToString(item.valorIPIDevolucao);
            var idev = new TNFeInfNFeDetImpostoDevol();
            idev.IPI = new TNFeInfNFeDetImpostoDevolIPI();
            idev.IPI.vIPIDevol = VIPIDEVOLVIDO;
            idev.pDevol = "100.00";
            oNotaXML.infNFe.det[i].impostoDevol = idev;
        }

        oNotaXML.infNFe.det[i].imposto.PIS = new TNFeInfNFeDetImpostoPIS();
        object ItemPis = null;

        var ItemPisOutr = new TNFeInfNFeDetImpostoPISPISOutr();
        ItemPisOutr.CST = TNFeInfNFeDetImpostoPISPISOutrCST.Item99;

        ItemPisOutr.Items = new string[2];
        ItemPisOutr.Items[0] = vBCPIS;
        ItemPisOutr.Items[1] = pPIS;

        ItemPisOutr.ItemsElementName = new CE_pPIS[2];
        ItemPisOutr.ItemsElementName[0] = CE_pPIS.vBC;
        ItemPisOutr.ItemsElementName[1] = CE_pPIS.pPIS;
        ItemPisOutr.vPIS = vPIS;

        ItemPis = ItemPisOutr;
        oNotaXML.infNFe.det[i].imposto.PIS.Item = ItemPis;

        oNotaXML.infNFe.det[i].imposto.COFINS = new TNFeInfNFeDetImpostoCOFINS();
        object ItemCOFINS = null;

        var itemCOFINSOutr = new TNFeInfNFeDetImpostoCOFINSCOFINSOutr();

        itemCOFINSOutr.Items = new string[2];
        itemCOFINSOutr.Items[0] = vBCCOFINS;
        itemCOFINSOutr.Items[1] = pCOFINS;

        itemCOFINSOutr.ItemsElementName = new CE_pCOFINS[2];
        itemCOFINSOutr.ItemsElementName[0] = CE_pCOFINS.vBC;
        itemCOFINSOutr.ItemsElementName[1] = CE_pCOFINS.pCOFINS;
        itemCOFINSOutr.vCOFINS = vCOFINS;

        itemCOFINSOutr.CST = TNFeInfNFeDetImpostoCOFINSCOFINSOutrCST.Item99;

        ItemCOFINS = itemCOFINSOutr;
        oNotaXML.infNFe.det[i].imposto.COFINS.Item = ItemCOFINS;

        if (oNotaXML.infNFe.det[i].imposto.Items == null)
            oNotaXML.infNFe.det[i].imposto.Items = new object[1];

        var itemICMS = new TNFeInfNFeDetImpostoICMS();

        oNotaXML.infNFe.det[i].imposto.Items[0] = itemICMS;
        if (item.csosnICMS == CSOSNICMS.Vazio)
            throw new Exception("CSOSN (ICMS) deve ser informado.");

        switch (item.csosnICMS)
        {
            case CSOSNICMS.ItemSIMPLES101:
            {
                itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN101();
                ((TNFeInfNFeDetImpostoICMSICMSSN101)itemICMS.Item).CSOSN = TNFeInfNFeDetImpostoICMSICMSSN101CSOSN.Item101;
                ((TNFeInfNFeDetImpostoICMSICMSSN101)itemICMS.Item).orig = Torig.Item0;
                ((TNFeInfNFeDetImpostoICMSICMSSN101)itemICMS.Item).pCredSN = "0.0000";
                ((TNFeInfNFeDetImpostoICMSICMSSN101)itemICMS.Item).vCredICMSSN = "0.00";
                break;
            }
            case CSOSNICMS.ItemSIMPLES102:
            case CSOSNICMS.ItemSIMPLES103:
            case CSOSNICMS.ItemSIMPLES300:
            case CSOSNICMS.ItemSIMPLES400:
            {
                itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN102();
                ((TNFeInfNFeDetImpostoICMSICMSSN102)itemICMS.Item).CSOSN =
                        item.csosnICMS == CSOSNICMS.ItemSIMPLES102 ? TNFeInfNFeDetImpostoICMSICMSSN102CSOSN.Item102 :
                        item.csosnICMS == CSOSNICMS.ItemSIMPLES103 ? TNFeInfNFeDetImpostoICMSICMSSN102CSOSN.Item103 :
                        item.csosnICMS == CSOSNICMS.ItemSIMPLES300 ? TNFeInfNFeDetImpostoICMSICMSSN102CSOSN.Item300 :
                        TNFeInfNFeDetImpostoICMSICMSSN102CSOSN.Item400;

                ((TNFeInfNFeDetImpostoICMSICMSSN102)itemICMS.Item).orig = Torig.Item0;
                break;
            }
            case CSOSNICMS.ItemSIMPLES201:
            {
                itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN201();
                ((TNFeInfNFeDetImpostoICMSICMSSN201)itemICMS.Item).CSOSN = TNFeInfNFeDetImpostoICMSICMSSN201CSOSN.Item201;
                ((TNFeInfNFeDetImpostoICMSICMSSN201)itemICMS.Item).orig = Torig.Item0;
                break;
            }
            case CSOSNICMS.ItemSIMPLES202:
            case CSOSNICMS.ItemSIMPLES203:
            {
                itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN202();
                ((TNFeInfNFeDetImpostoICMSICMSSN202)itemICMS.Item).CSOSN =
                        item.csosnICMS == CSOSNICMS.ItemSIMPLES202 ? TNFeInfNFeDetImpostoICMSICMSSN202CSOSN.Item202 :
                        TNFeInfNFeDetImpostoICMSICMSSN202CSOSN.Item203;

                ((TNFeInfNFeDetImpostoICMSICMSSN202)itemICMS.Item).orig = Torig.Item0;
                break;
            }
            case CSOSNICMS.ItemSIMPLES500:
            {
                    itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN500();
                    ((TNFeInfNFeDetImpostoICMSICMSSN500)itemICMS.Item).CSOSN = TNFeInfNFeDetImpostoICMSICMSSN500CSOSN.Item500;
                    ((TNFeInfNFeDetImpostoICMSICMSSN500)itemICMS.Item).orig = Torig.Item0;

                    break;
            }
            case CSOSNICMS.ItemSIMPLES900:
            {
                itemICMS.Item = new TNFeInfNFeDetImpostoICMSICMSSN900();
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).CSOSN = TNFeInfNFeDetImpostoICMSICMSSN900CSOSN.Item900;
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).orig = Torig.Item0;
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).vBC = vBCICMS;
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).vICMS = vICMS;
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).pICMS = pICMS;
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).vBCST = "0.00";
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).pICMSST = "0.00";
                ((TNFeInfNFeDetImpostoICMSICMSSN900)itemICMS.Item).vICMSST = "0.00";
                break;
            }
        }

        oNotaXML.infNFe.det[i].imposto.IBSCBS = new TNFeInfNFeDetImpostoIBSCBS();

        if (item.cst != CST.Vazio)
            oNotaXML.infNFe.det[i].imposto.IBSCBS.CST = item.cst.GetDescription().Substring(0, 3);

        if (item.classificacaoTributaria != null)
            oNotaXML.infNFe.det[i].imposto.IBSCBS.cClassTrib = item.classificacaoTributaria.Sigla;

        var gIBSCBS = new TNFeInfNFeDetImpostoIBSCBSgIBSCBS();

        gIBSCBS.vIBS = vIBS;
        gIBSCBS.vBC = vBCIBSCBS;

        gIBSCBS.gCBS = new TNFeInfNFeDetImpostoIBSCBSgIBSCBSgCBS();
        gIBSCBS.gCBS.vCBS = vCBS;
        gIBSCBS.gCBS.pCBS = pCBS;

        gIBSCBS.gIBSMun = new TNFeInfNFeDetImpostoIBSCBSgIBSCBSgIBSMun();
        gIBSCBS.gIBSMun.pIBSMun = pIBSMunicipio;
        gIBSCBS.gIBSMun.vIBSMun = vIBSMunicipio;

        gIBSCBS.gIBSUF = new TNFeInfNFeDetImpostoIBSCBSgIBSCBSgIBSUF();
        gIBSCBS.gIBSUF.vIBSUF = vIBSUF;
        gIBSCBS.gIBSUF.pIBSUF = pIBSUF;

        oNotaXML.infNFe.det[i].imposto.IBSCBS.Item = gIBSCBS;

        i++;
    }

    oNotaXML.infNFe.total = new TNFeInfNFeTotal();
    oNotaXML.infNFe.total.ICMSTot = new TNFeInfNFeTotalICMSTot();

    string vBCTOTAL = DecimalToString(np.bctotal);
    string vICMSTOTAL = DecimalToString(np.icmstotal);
    string vPISTOTAL = DecimalToString(np.pistotal);
    string vIPITOTAL = DecimalToString(np.ipitotal);
    string vCOFINSTOTAL = DecimalToString(np.cofinstotal);
    string vCBSTOTAL = DecimalToString(np.cbstotal);
    string vIBSTOTAL = DecimalToString(np.ibstotal);
    string vIBSTOTALMUNICIPIO = DecimalToString(np.ibstotalMunicipio);
    string vIBSTOTALUF = DecimalToString(np.ibstotalUF);
    string vProd = DecimalToString(np.itens.Sum(x => x.quantidade * x.valorUnitario));
    string vCBSIBSTOTAL = DecimalToString(np.cbstotal + np.ibstotal);
    string vBCIBSCBSTOTAL = vProd;

    oNotaXML.infNFe.total.ICMSTot.vBC = vBCTOTAL;
    oNotaXML.infNFe.total.ICMSTot.vICMS = vICMSTOTAL;
    oNotaXML.infNFe.total.ICMSTot.vICMSDeson = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vFCPUFDest = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vICMSUFDest = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vICMSUFRemet = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vBCST = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vFCP = "0.00";

    oNotaXML.infNFe.total.ICMSTot.vST = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vFCPST = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vFCPSTRet = "0.00";

    oNotaXML.infNFe.total.ICMSTot.vProd = vProd;


    var ValorNotaFiscal = DecimalToString(np.valorNF);

    oNotaXML.infNFe.total.ICMSTot.vNF = ValorNotaFiscal;

    if (oNotaXML.infNFe.pag.detPag[0].tPag == TNFeInfNFePagDetPagTPag.Item90) // Sem Pagamento
        oNotaXML.infNFe.pag.detPag[0].vPag = "0.00";
    else
        oNotaXML.infNFe.pag.detPag[0].vPag = ValorNotaFiscal;

    if (devolverIPI)
        oNotaXML.infNFe.total.ICMSTot.vNF = DecimalToString(np.valorNF + totalIPIDevolucao);

    oNotaXML.infNFe.total.ICMSTot.vFrete = DecimalToString(np.itens.Sum(x => x.valorFrete));

    oNotaXML.infNFe.total.ICMSTot.vSeg = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vDesc = DecimalToString(np.itens.Sum(x => x.valorDesconto));
    oNotaXML.infNFe.total.ICMSTot.vII = "0.00";

    oNotaXML.infNFe.total.ICMSTot.vIPI = vIPITOTAL;
    oNotaXML.infNFe.total.ICMSTot.vIPIDevol = strVIPIDEV;

    oNotaXML.infNFe.total.ICMSTot.vPIS = vPISTOTAL;
    oNotaXML.infNFe.total.ICMSTot.vCOFINS = vCOFINSTOTAL;
    oNotaXML.infNFe.total.ICMSTot.vOutro = "0.00";
    oNotaXML.infNFe.total.ICMSTot.vTotTrib = "0.00";

    oNotaXML.infNFe.total.IBSCBSTot = new TNFeInfNFeTotalIBSCBSTot();
    oNotaXML.infNFe.total.IBSCBSTot.gIBS = new TNFeInfNFeTotalIBSCBSTotgIBS();
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSMun = new TNFeInfNFeTotalIBSCBSTotgIBSgIBSMun();
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSMun.vIBSMun = vIBSTOTALMUNICIPIO;
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSMun.vDif = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSMun.vDevTrib = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSUF = new TNFeInfNFeTotalIBSCBSTotgIBSgIBSUF();
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSUF.vIBSUF = vIBSTOTALUF;
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSUF.vDif = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.gIBSUF.vDevTrib = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.vIBS = vIBSTOTAL;
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.vCredPres = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gIBS.vCredPresCondSus = "0.00";


    oNotaXML.infNFe.total.IBSCBSTot.gCBS = new TNFeInfNFeTotalIBSCBSTotgCBS();
    oNotaXML.infNFe.total.IBSCBSTot.gCBS.vCBS = vCBSTOTAL;
    oNotaXML.infNFe.total.IBSCBSTot.gCBS.vDif = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gCBS.vDevTrib = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gCBS.vCredPres = "0.00";
    oNotaXML.infNFe.total.IBSCBSTot.gCBS.vCredPresCondSus = "0.00";

    oNotaXML.infNFe.total.IBSCBSTot.vBCIBSCBS = vBCIBSCBSTOTAL;

    oNotaXML.infNFe.transp = new TNFeInfNFeTransp();

    if (np.tipoModalidadeFrete == TipoModalidadeFrete.Emitente)
        oNotaXML.infNFe.transp.modFrete = TNFeInfNFeTranspModFrete_v400.Item0;
    else if (np.tipoModalidadeFrete == TipoModalidadeFrete.Remetente)
        oNotaXML.infNFe.transp.modFrete = TNFeInfNFeTranspModFrete_v400.Item1;
    else if (np.tipoModalidadeFrete == TipoModalidadeFrete.Terceiros)
        oNotaXML.infNFe.transp.modFrete = TNFeInfNFeTranspModFrete_v400.Item2;
    else if (np.tipoModalidadeFrete == TipoModalidadeFrete.SemFrete)
        oNotaXML.infNFe.transp.modFrete = TNFeInfNFeTranspModFrete_v400.Item9;


    oNotaXML.infNFe.infAdic = new TNFeInfNFeInfAdic();

    if (!String.IsNullOrEmpty(np.observacoes))
    {
        var obs = np.observacoes.Replace("\n", "").Trim();
        if (!String.IsNullOrEmpty(obs))
            oNotaXML.infNFe.infAdic.infCpl = obs;
    }

    Random random = new Random();

    string cUF = np.uf.codigoIBGE.ToString("00");
    string AAMM = np.dataEmissao.ToString("yyMM");
    string CNPJ = np.documentoEmitente;
    string mod = "55";
    string serie = np.serie.ToString("000");
    string nNF = np.numero.ToString("000000000");
    string tpEmis = ((int)np.modoEmissao).ToString();
    string cNF = random.Next(99999999).ToString("00000000");

    string NFeKey = string.Format("{0}{1}{2}{3}{4}{5}{6}{7}",
            cUF, AAMM, CNPJ, mod, serie, nNF, tpEmis, cNF);
    string cDV = DvBase11(NFeKey);

    oNotaXML.infNFe.Id = string.Format("NFe{0}{1}", NFeKey, cDV);
    oNotaXML.infNFe.versao = "4.00";
    oNotaXML.infNFe.ide.cNF = cNF;
    oNotaXML.infNFe.ide.nNF = np.numero.ToString();
    oNotaXML.infNFe.ide.tpEmis = TNFeInfNFeIdeTpEmis.Normal;
    oNotaXML.infNFe.ide.cDV = cDV;
    oNotaXML.infNFe.ide.mod = TMod.Item55;
    oNotaXML.infNFe.ide.serie = np.serie.ToString();


    return oNotaXML;


}
